The differential pressure switch housing unit contains a diaphragm, a snap-acting SPDT switch, and a range adjustment knob with increments.
The sample connections located on the side accept 6.35mm (0.25”) OD tubing. There are various optional pressure ranges, and 2 pickup tubes and 2 m (6.56’) of PVC tubing available. The enclosure cover guards against accidental contact with the live switch terminal screws and the setpoint adjustment knob with indication.
Available in 3 range options, please specify which model is required on any order:
GFS-80U-NPIKG Air D/P Switch, 20-300 Pa adj. range, 1/2"NPT connection
GFS-83U-NPIKG Air D/P Switch, 50-500 Pa adj. range, 1/2"NPT connection
GFS-86U-NPIKG Air D/P Switch, 500-2500 Pa adj. range, 1/2"NPT connection
The differential pressure switch housing unit contains a diaphragm, a snap-acting SPDT switch, and a range adjustment knob with increments.
The sample connections located on the side accept 6.35mm (0.25”) OD tubing. There are various optional pressure ranges, and 2 pickup tubes and 2 m (6.56’) of PVC tubing available. The enclosure cover guards against accidental contact with the live switch terminal screws and the setpoint adjustment knob with indication.
Available in 3 range options, please specify which model is required on any order:
GFS-80U-NPIKG Air D/P Switch, 20-300 Pa adj. range, 1/2"NPT connection
GFS-83U-NPIKG Air D/P Switch, 50-500 Pa adj. range, 1/2"NPT connection
GFS-86U-NPIKG Air D/P Switch, 500-2500 Pa adj. range, 1/2"NPT connection
