DT9817-R Low Cost USB Digital I/O Module; 16 DIO, 500V Isolation

£51100

(£613.20 incl VAT)
FREE delivery to UK on orders over £500

100% Money Back
30 Day Guarantee

International Shipping
Over 100 Countries

Model:DT9817-R

Description

The DT9817 Series of USB digital I/O devices provide support for solid-state or mechanical relays. These devices are available with isolation, high current output and AC/DC signal sensing.

Features

16 opto-isolated digital I/O lines
DT9817-R additional features:
±500V isolation channel-to-channel
AC or DC input signal sensing from ±3V to ±32V
Switch up to ±30V at 400 mA peak
32-bit counter/timer supports: event counting, frequency measurement, edge-to-edge measurement, and rate generation.
Bus-powered for portability
Shielded, rugged enclosure for noise immunity
Built-in screw terminals
Included software and drivers

Specifications

Digital I/O
Channels	Counter/Timers	Encoder Inputs
Up to 28	1	—

Technical

Data Sheet

User Manual

Description

The DT9817 Series of USB digital I/O devices provide support for solid-state or mechanical relays. These devices are available with isolation, high current output and AC/DC signal sensing.

Features

16 opto-isolated digital I/O lines
DT9817-R additional features:
±500V isolation channel-to-channel
AC or DC input signal sensing from ±3V to ±32V
Switch up to ±30V at 400 mA peak
32-bit counter/timer supports: event counting, frequency measurement, edge-to-edge measurement, and rate generation.
Bus-powered for portability
Shielded, rugged enclosure for noise immunity
Built-in screw terminals
Included software and drivers
